Description |
DS-15 |
DS-20 |
DS-25 |
DS-30 |
||
Max. Drilling Diameter |
1800mm |
1800mm |
1800mm |
1800mm |
||
Max. Drilling Depth |
15m |
20m |
25m |
30m |
||
Rotary Drive |
Max. output torque |
80kN .m |
80kN .m |
80kN .m |
80kN .m |
|
Rotary speed |
17-40r/min |
17-40r/min |
17-40r/min |
17-40r/min |
||
Hydraulic System |
System pressure |
35Mpa |
35Mpa |
35Mpa |
35Mpa |
|
Oil Tank capacity |
380L |
400L |
425L |
450L |
||
Mast |
Height of mast |
10,000mm |
10,000mm |
11,500mm |
12,500mm |
|
Inclination left/right |
2-3° |
2-3° |
2-3° |
2-3° |
||
Inclination front |
5° |
5° |
5° |
5° |
||
Overall Drilling Weight
|
22T |
24T |
26T |
28T |
||
Dimension |
Working (L*W*H)
Transportation condition (L*W*H) |
4800*2300*9600 8600*2300*3400 (mm) |
5700*2600*10500 9610*2600*3500 (mm) |
5700*2600*11500 10100*2600*3500 (mm) |
6000*2600*12500 11600*2600*3500 (mm) |
Henan Disy Machinery Co., Ltd. It is a comprehensive enterprise integrating piling and drilling rig design, manufacture and installation.
1. Good quality control.
2. Highly competitive prices.
3. State-of-art technology products.
4. Our well drilling rig sales in China first, China's largest well drilling rig manufacturer.
5. Smooth communication.
1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, pile drivers, etc.
The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance.
If you need, we can send our engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
